The LUX HALOGEN COMPACT is a machine designed to expose the screen printing screen. The machine is equipped with a halogen light source unit with instant ON / OFF which achieves better energy efficiency.
-
| LUXDRYER HALOGEN COMPACT |
LX COMP 0608 |
LX COMP 0709 |
LX COMP 0913 |
LX COMP 1215 |
| Frame dimension |
60 x 80 cm |
70 x 90 cm |
90 x 130 cm |
125 x 150 cm |
| Power of the halogen lamp |
3 kW RAPID |
3 kW RAPID |
3 kW RAPID |
5 kW RAPID |
| Dimension (Depth / Width / Height) |
120 x 100 x 110 cm |
100 x 120 x 110 cm |
120 x 160 x 115 cm |
150 x 185 x 145 cm |
| Max printing speed at 600 dpi |
3200 m² / h |
3200 m² / h |
3200 m² / h |
5200 m² / h |
| Weight |
250 kg |
300 kg |
350 kg |
450 kg |
| Power supply |
3 x 400 V |
3 x 400 V |
3 x 400 V |
3 x 400 V |
